Usage:
Suitable for the mid/long distance transportation of the mid/heavy duty and bulk cargo
Features:
The whole body adopts steel with good quality, and be manufactured by advanced skills and strict producing managerial processes.
The frame is wearing structure, webs made from manganese plates from 400mm to 550mm high welded the upper and lower flangeplates together, and the beam runs through the longitudinal beam makes the two parts a very strong unit by automatic submerged arc welding.
Specifications:
| Size | 12500*2500*1500 (mm) |
| Side board height | 800-1500mm optional |
| Payload | 50000KG |
| Main beam | Heavy duty I beam. |
| Cross beam | 160mm |
| Plate | checked plate or flat plate |
| Axles | 3 * 13ton capacity (Brand optional) |
| Suspension | Mechanical suspension (Air suspension optional) |
| Leaf spring | 10pcs |
| Tire | 12R22.5 12pcs (Other size optional) |
| Rim | 9.00-22.5 12pcs (Other size optional) |
| Kin pin | 2’’/3.5’’ bolt type |
| Landing gear | 28 Ton two speed |
| Twist locks | optional |
| Braking system | Double air chamber ,brake valve,40L air tanks ;ABS optional |
| Electrical | LED light , 7 ways ,24V |
| Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting |
FAQ:
1. How do you make the shipment?
We will transport the trailers by bulk or cotainer,we have possess longterm cooperation with ship agency who can provide you lowest shipping fee.
2. Can you satisfy my special requirement?
Sure! We are direct manufacturer with 30 years experience and we have strong producing capacity and R&D capacity.
3. How can you guarantee quality?
Our raw material and OEM parts including axle, suspension,tyre are purchased centralized by ourselves,every part will be inspected strictly.Moreover,advanced equipment rather than only worker is been applied during the whole producing process to ensure the welding quality.
4. Can I have samples of this type of trailer to test the quality?
Yes, you can buy any samples to test the quality,our MOQ is 1 set.
5. What's the delivery time and can you lower the price?
It depends on your order. The delivery time is 20 workdays after we received your prepayment. If you have place an order of large quantities, then ,of course, the price can be lowered.
6.Can I customize the painting and the logo?
Yes, we offer customized logo for any type.
7.What's the payment method?
TT 30% as Deposit, Balance Before shipment by TT or L/C at sight.
Product Tags:
|
|
Flat Platform With Detachable Side Wall Semi Trailers For Cargo Transport Images
|
